| 型號 |
RP-CQMC-V200A |
RP-CQMC-V200A/CS |
RP-CQMC-V200A/HD |
RP-CQMC-V12/HB |
| 適用機型 |
多針有機梭頭 |
多針無機梭頭 |
多針旋梭機 |
單頭機 |
| 針排距 |
Needle space 1”,row space 3 2or3or nonstandard needle-row space |
Needle space 25mm,row space 75mm2or3or nonstandard needle-row space |
Needle space 200mm,row space 300mm1or2or nonstandard needle-row space |
Single head |
| 針跡 |
2.0-6.0mm,lock stitch |
2.0-6.0mm,lock stitch |
2.0-6.0mm,lock stitch |
2.0-6.0mm,lock stitch |
| 絎縫厚度 |
≤30mm |
≤50mm |
≤30mm |
≤30mm |
| 主軸速度 |
100-600rpm |
100-700rpm |
500-1500rpm |
500-2500rpm |
| 產量 |
72-216m/hr |
84-252m/hr |
180-540m/hr |
5-15m/min |
| 花版設計 |
Within20”×40”punching or changing directly by patterns |
Within500mm×1000mm punching or changing directly by patterns |
Within500mm×1000mm punching or changing directly by patterns |
Within2.5m×2.5mpunching or changing directly by patterns |
| 高位停機 |
安裝 |
| 斷線自動停機 |
可選項 |
| 主控電腦 |
專業工控版 |
| 操作界面 |
15"VGA_CRT,mouse,digital LED,speacial industrial keyboard |
| 花版存儲 |
200fixed+300 changable patterns |
500 position changable-patterns |
| 花版適用 |
Simulative fabric/thread,256-color available |
| 工作時間 |
24-hour continuous work |
| 電源 |
AC380V±10%/50Hz,3.5KVA 3-Phase,3-line power |
| 包裝尺寸 |
620（W）*520（D）*1580（H)mm |
620（W）*520（D）*1580（H)mm |
620（W）*520（D）*1580（H)mm |
620（W）*520（D）*1580（H)mm |
